Description:

Introducing the RSM-4 relay, a versatile component functioning on 24VAC or DC voltage, featuring a single changeover contact This model adheres to all RoHS standards, certified with the number E141197, though it is currently marked as discontinued Its compact dimensions measure 66 mm deep, 87 mm tall, and 69 mm wide, with a lightweight of 107988 grams For optimal performance, store this relay in temperatures between -40 to 60 °C, while it operates effectively within a range of -25 to 50 °C.

Features and Benefits:

    •LED status display is green.

    •Connection on the field side is LMFS 5.08 mm.

    •Connection on the control side is LMFS 5.08 mm.

    •Mechanical service life is rated at 30 x 10^6 switching cycles.

Specifications:

 Depth 66 mm
 Height 87 mm
 Width 69 mm
 Operating temperature UL, max. 25 °C
 Operating temperature UL, min. 0 °C
 Rated voltage AC U N (input) 24 V
 Rated voltage DC U N (input) 24 V
 Rated voltage AC U N (output) 250 V
 Rated current I max (output) 4.6 A
 Input voltage 24 V AC ± 10%, 24 V DC ± 10%
 Input current DC 22.9 mA / AC 13.9 mA
 Relay type RCL
 Type of output Potential-free contact
 Material of contacts AgNi 90/10
 Rated voltage ≤ 250 V AC
 Max. AC continuous current 6 A
 Minimum contact current 0.1 A
 Minimum contact voltage 5 V
 Insulation coordination (EN50178) Pollution severity level 2
 Pulse voltage test (1,2/50μs) 6 kV
 Insulation test voltage AC 1.2 kV
 Clearance input/output ≥ 5.5 mm
 Clamping range, max. 2.5 mm²
 Clamping range, min. 0.12 mm²
 Max. wire cross-section, AWG AWG 12
 Min. wire cross-section, AWG AWG 26
 Stripping length 10 mm
