1428150000 - 44-Pole High-Density Connector, 71mm Depth, RoHS Compliant

1428150000 - 44-Pole High-Density Connector, 71mm Depth, RoHS Compliant

SKU: 1428150000 Download PDF

Variant:
  • 1428150000 - 44-Pole High-Density Connector, 71mm Depth, RoHS Compliant
Now $71.46
BEFORE   $0.00 Now $71.46
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS SD44F HD UNC440 S, a robust SUB-D plug-in connector that boasts a 44-pole socket secured with a reliable screw connection This connector adheres to RoHS standards and carries an exemption marking It measures 95 mm in width, 70 mm in height, and has a depth of 71 mm, while its weight is a manageable 16157 grams With operational capabilities spanning from -25 to 50 °C, it's also designed for storage at temperatures ranging from -40 to 60 °C, making it a versatile choice for various applications.

Features and Benefits:

    •High-density SUB-D plug-in connector.

    •Screw connection for secure connections.

    •Suitable for various applications per environmental compliance requirements.

Specifications:

 Depth 71 mm
 Height 70 mm
 Width 95 mm
 Rated voltage 125 V AC / 175 V DC
 Rated current I max 1 A
 Insulation coordination (EN50178) According to DIN EN 50178
 Rated insulation voltage 125V AC / 175 V DC
 Surge voltage category II
 Pollution severity level 2
 Pulse voltage test (1,2/50μs) 1.15 kV
 Insulation test voltage AC 0.65 kV
 Connection data LL3R 5.08 mm
 Earthing No
 Number of poles (control side) 44-pole socket
 Clamping range, max. 6 mm²
 Clamping range, min. 0.5 mm²
 Flexible with sleeve, max. 2.5 mm²
 Flexible with sleeve, min. 0.5 mm²
 Flexible, max. H05(07) V-K 4 mm²
 Flexible, min. H05(07) V-K 0.5 mm²
 Max. wire cross-section, AWG AWG 12
 Min. wire cross-section, AWG AWG 26
 Stripping length 6 mm
 Tightening torque, max. 0.6 Nm
 Tightening torque, min. 0.5 Nm
