0646660000 - DIN 41612 64-Pole Female Connector, RoHS Compliant

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SKH C64 RH2, a precision-engineered interface plug-in connector that adheres to DIN 41612 specifications Boasting a robust 64-pole female connection, this connector is designed with compliance to RoHS standards and is free from SVHC substances exceeding the 01 wt% threshold Measuring 144 mm in depth, 76 mm in height, and 131 mm in width, it has a lightweight design at just 277 grams.

The SKH C64 RH2 thrives in a diverse range of temperatures, operating effectively between 0 to 55 °C and withstanding storage conditions from -40 to 60 °C It supports a rated voltage of 125V AC / 150V DC, also accommodating a maximum current of 1 A per connection, making it a reliable choice for your connectivity needs.

Features and Benefits:

•RoHS compliant without exemption.

•Suitable for 19" racks with a design in a 100x160 mm Euro format.

•Includes a screw connection type.

•Provides a clamping range between 0.5 mm² and 6 mm².

•Offers maximum wire cross-section compatibility of AWG 12.

Specifications:
