0224961001 - IEC60603-13 10-Pole Plug Connector with Screw Connection

0224961001 - IEC60603-13 10-Pole Plug Connector with Screw Connection

SKU: SKU: 0224961001   Download PDF

Select a Variant:
  • 0224961001 - IEC60603-13 10-Pole Plug Connector with Screw Connection
Qty:
Regular price Now $34.97   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $34.97 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Experience reliable connectivity with the RS F10 LP2N 5/10 connector This 10-pole, plug-in connector is crafted to meet IEC60603-13 and DIN41651 specifications, featuring a secure screw connection for enhanced performance It is RoHS compliant and comes with a UL certification (E141197), ensuring safety and quality in your electrical applications.

Features and Benefits:

    •Compliant with RoHS without exemption.

    •UL certified.

    •Supports operating temperatures from 0 to 55 °C.

Specifications:

 Depth 70 mm
 Height 87 mm
 Width 50 mm
 Rated current I N 1 A
 Rated voltage U N ≤ 60 V AC / 75 V DC
 Insulation coordination (EN50178) According to DIN EN 50178
 Rated insulation voltage 100 V
 Surge voltage category II
 Pollution severity level 2
 Clamping range, max 6 mm²
 Clamping range, min 0.5 mm²
 Max. wire cross-section, AWG AWG 12
 Min. wire cross-section, AWG AWG 26
 Type of connection Screw connection
