Product Information

Description:

Introducing the RSM-8, a versatile solution for both 115VAC and DC applications, featuring a reliable screw connection interface This device adheres to RoHS standards and boasts UL certification (certificate number E141197) Measuring 130mm in width, 87mm in height, and 66mm in depth, the unit has a lightweight design at just 254g It operates effectively within a temperature range of -25°C to 50°C and can be stored in conditions as extreme as -40°C to 60°C.

Capable of handling an input voltage of 115VAC/DC, the RSM-8 offers a rated current output of 46A, with a maximum continuous AC current of 6A.

Features and Benefits:

•UL certified with E141197.

•RoHS compliant.

•Screw connection interface.

•Rated for a mechanical service life of 30 x 10^6 switching cycles.

•LED status display in green.

•Potential-free contact output type.

Specifications:

Operating temperature (max)	50 °C
Operating temperature (min)	-25 °C
Input voltage	115 VAC/DC ± 10%
Rated current (input)	4.8 mA
Rated voltage (output)	≤ 250 V AC
Max. AC continuous current	6 A
Minimum contact current	0.1 A
Minimum contact voltage	5 V
Insulation test voltage AC	1.2 kV
Connection (field side)	LL 5.08 mm
Connection (control side)	LP 5.08 mm
Clamping range (max)	6 mm²
Clamping range (min)	0.5 mm²
Stripping length	6 mm
Tightening torque (max)	0.6 Nm
Tightening torque (min)	0.5 Nm
