1447840000 - RSM-8 12V Power Supply, 130mm x 87mm x 66mm, RoHS Compliant

1447840000 - RSM-8 12V Power Supply, 130mm x 87mm x 66mm, RoHS Compliant

SKU: 1447840000   Download PDF

Select a Variant:
  • 1447840000 - RSM-8 12V Power Supply, 130mm x 87mm x 66mm, RoHS Compliant
Qty:
Now $118.20   Web pricing policy
BEFORE   $0.00 Now $118.20 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the RSM-8 12V+ 1CO Z, a versatile device engineered for various applications and compliant with RoHS standards It boasts a compact design with dimensions of 66 mm in depth, 87 mm in height, and 130 mm in width, while weighing just 258 g This model is designed to function optimally in temperatures ranging from -25 to 50 degrees Celsius, with impressive storage capabilities extending between -40 and 60 degrees Celsius.

Equipped with a range of rated input and output settings, this reliable device is perfect for your specific needs.

Features and Benefits:

    •LED status display for each relay provided in green.

    •Supply voltage status indicated with a yellow LED.

    •Connection on the field side is through LMFS 5.08 mm.

    •Total mechanical service life rated for 30 million switching cycles.

Specifications:

 UL File Number E141197
 Operating temperature (UL, max) 25 °C
 Operating temperature (UL, min) 0 °C
 Rated voltage DC (supply) 12 V
 Rated current (supply) 1 A
 Rated voltage DC (input) 12 V
 Rated voltage AC (output) 250 V
 Rated current (output) 4.6 A
 Input voltage 12 V DC ± 10%
 Input current 33 mA
 Relay type RCL
 Type of output Potential-free contact
 Material of contacts AgNi 90/10
 Rated voltage (output) ≤ 250 V AC
 Max. AC continuous current 6 A
 Minimum contact current 0.1 A
 Minimum contact voltage 5 V
 Insulation coordination (EN50178) Pollution severity level 2
 Pulse voltage test (1,2/50μs) 6 kV
 Insulation test voltage AC 1.2 kV
 Rated input insulation voltage <50 V AC
 Rated output insulation voltage 250 V AC
 Overvoltage category input/output III
 Overvoltage category output/output II
 Clearance input/output ≥ 5.5 mm
 Clamping range, max 2.5 mm²
 Clamping range, min 0.12 mm²
 Stripping length 10 mm
 Type of connection PUSH IN
