Description:
Enhance your fieldbus system connectivity with this efficient passive field distributor, tailored for Profibus PA and Foundation Fieldbus H1 setups With robust IP66/IP67 protection standards, it seamlessly integrates up to eight field devices into a single fieldbus segment Additionally, it accommodates multiple earthing arrangements, including both multi-point and single-point screen earthing options, in compliance with Profibus PA and Foundation Fieldbus specifications.
Features and Benefits:
•4-way distributor.
•Suitable for surface mounting.
•Constructed from rust-proof stainless steel and aluminum.
•Designed with a pressure compensation element.
•Complies with IP65 and IP66 protection degrees.
Specifications:
| Depth | 62.5 mm |
| Height | 36 mm |
| Width | 125 mm |
| Storage temperature | -40 °C...80 °C |
| Ambient temperature | -40 °C…80 °C |
| Operating temperature | -40 °C...80 °C |
| Humidity | 5...95 %, no condensation |
| Clamping range, min. | 4 mm² |
| Clamping range, max. | 6 mm² |
| Bus system | Profibus-PA, Foundation Fieldbus |
| Cable entry | Round |
| Conductor O.D., max. | 9.5 mm |
| Conductor O.D., min. | 6.5 mm |
| Connection type PE | Spur line with cable gland |
| Number of poles | 3 |
| Operating voltage | 30 V |
| Pollution severity | 3 |
