Description:
Introducing a robust passive field distributor, specifically engineered for Profibus PA and Foundation Fieldbus H1 systems With protection ratings of IP66 and IP67, this device ensures reliable operation even in challenging conditions It allows for seamless connections with up to eight field devices within a single fieldbus segment and accommodates various earthing methods in accordance with the guidelines of the respective fieldbus systems.
Perfect for enhancing your setup in demanding environments.
Features and Benefits:
•IP65 and IP66 protection degree.
•Supports earthing concepts for improved safety.
•Can connect up to eight field devices.
Specifications:
| Depth | 34 mm |
| Height | 37 mm |
| Width | 58 mm |
| Net weight | 262 g |
| Storage temperature | -40 °C...80 °C |
| Ambient temperature | -40 °C…80 °C |
| Operating temperature | -40 °C...80 °C |
| Humidity | 5 to 95 % (non-condensing) |
| Clamping range, min. | 4 mm² |
| Clamping range, max. | 6 mm² |
| Bus system | Profibus-PA, Foundation Fieldbus |
| Conductor O.D., max. | 9.5 mm |
| Conductor O.D., min. | 6.5 mm |
| Connection type PE | Spur line with cable gland |
| Contact carrier material | Brass |
| Contact material | CuZnAu |
| Design of housing | With pressure compensation element |
| Housing main material | Aluminium, AISi12 |
| Housing surface | powder coating |
| Number of contact sockets | 1 |
| Number of poles | 3 |
| Operating voltage | 30 V |
| Pollution severity | 3 |
| Type of distribution | 1-way distributor |
| Type of mounting | surface-mounted |
