Description:
Introducing a passive field distributor crafted for the Profibus PA fieldbus system, built to withstand demanding environments with an impressive IP66/IP67 protection rating This distributor is engineered to connect a single field device to a fieldbus segment, providing versatile earthing options compliant with Profibus standards, allowing for both multi-point and single-point screen earthing Experience reliable performance in even the toughest conditions.
Features and Benefits:
•Compliant with RoHS standards.
•Active in a temperature range from -40 °C to 80 °C.
•Supports humidity levels from 5% to 95% without condensation.
•Constructed with aluminum housing that is stove enamelled.
•Features a pressure compensation element.
Specifications:
| Depth | 34 mm |
| Height | 34 mm |
| Width | 64 mm |
| Clamping range, min. | 4 mm² |
| Clamping range, max. | 6 mm² |
| Number of poles | 3 |
| Operating voltage | 30 V DC |
| Protection degree | IP65, IP66 |
| Bus system | Profibus-DP, Modbus RS485 |
| Ambient temperature | -40 °C to 80 °C |
| Storage temperature | -40 °C to 80 °C |
| Operating temperature | -40 °C to 80 °C |
| Pollution severity | 3 |
| Cable entry | Brass cable gland |
| Design of housing | With pressure compensation element |
