Description:
Enhance your fieldbus systems with this innovative passive field distributor, expertly crafted for seamless compatibility with systems like Profibus PA and Foundation Fieldbus H1 With an impressive IP66/IP67 protection rating, it guarantees dependable operation in a wide range of environments This distributor can link up to eight field devices within a single fieldbus segment, supporting both multi-point and single-point screen earthing concepts as per industry standards.
Features and Benefits:
•IP65, IP66 protection degree.
•Complies with RoHS and environmental standards.
•Allows for multiple connections with up to eight devices.
•Designed with a pressure compensation element in housing.
Specifications:
| Depth | 34 mm |
| Height | 37 mm |
| Width | 80 mm |
| Storage temperature | -40 °C to 80 °C |
| Ambient temperature | -40 °C to 80 °C |
| Operating temperature | -40 °C to 80 °C |
| Clamping range, min. | 4 mm² |
| Clamping range, max. | 6 mm² |
| Bus system | Profibus-PA, Foundation Fieldbus |
| Cable entry | Round |
| Conductor O.D., max. | 9.5 mm |
| Conductor O.D., min. | 6.5 mm |
| Contact carrier material | Brass |
| Contact material | CuZnAu |
| Housing main material | Aluminium AISi12 |
| Housing surface | powder coating |
| Number of contact sockets | 4 |
| Number of poles | 3 |
| Operating voltage | 30 V |
| Pollution severity | 3 |
| Type of distribution | 4-way distributor |
| Type of mounting | surface-mounted |
