1102200040 - 4m M12 D-Code System Cable, IP67 Rated, PVC

SKU: SKU: 1102200040 Download PDF

Select a Variant:

1102200040 - 4m M12 D-Code System Cable, IP67 Rated, PVC

SET THE QTY:

Now $64.89 Web pricing policy

~~BEFORE $0.00~~ Now $64.89 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Introducing a 4-meter long system cable equipped with an M12 D-code connector, boasting an IP 67 rating for the straight pin and an IP 20 rating for the RJ45 port This cable complies with Cat 5 standards in alignment with ISO/IEC 11801 and TIA T568-B guidelines The durable outer jacket is crafted from high-quality PVC material, ensuring reliable performance in various environments Perfect for your connectivity needs!.

Features and Benefits:

•Compliant with RoHS standards.

•Environmental product compliance including exemption for certain substances.

•Complete shielding with aluminium foil and copper braid.

•Suitable for a range of temperatures from -40 °C to 80 °C for storage and installation.

Specifications:

Length	4 m
Diameter of inner sheathing	4.05 mm
Sheath diameter, max.	6.7 mm
Sheath diameter, min.	6.3 mm
Sheathing material thickness	0.9 mm
Min. bending radius, once only	3.5 *diameter
Min. bending radius, repetitive	7.5 x cable diameter
Operating voltage	600 V
Loop resistance	120 Ω/km
Characteristic impedance	100 ± 5 Ω at 100 MHz
Signal propagation time	5.3 ns/m
Test voltage: wire-wire-shield	2000 V, 50 Hz, 1 min
Transfer impedance	20 mΩ/m at 10 MHz
Cable Category	Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B)
