1068940000 - 5-Pole 24V PROFINET Connector, 16A, RoHS Compliant (Pack of 100)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the IE-BID-24V, a high-performance PROFINET socket connector designed to meet ROHS compliance This durable connector boasts a five-pole configuration and is rated for up to 100 plugging cycles, ensuring long-lasting reliability Constructed from a copper alloy with a gold over nickel finish, it guarantees superior conductivity This unshielded connector supports an operating voltage of 24V and can handle a current of 16A, facilitating optimal performance even at an ambient temperature of 50 °C.

Furthermore, its operational temperature range extends from -40 °C to 70 °C, making it suitable for a variety of demanding environments.

Features and Benefits:

•Compliant with ROHS without exemption.

•Contact surface made of gold over nickel.

•Five poles for connectivity.

•Rated for ≤ 100 plugging cycles.

Specifications:
