2555940000 - IP20 Remote I/O Module for RTD Sensors, 76mm Depth

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing our advanced remote I/O module, perfect for IP20-rated environments Engineered to handle analog signals linked to temperature measurement via RTD sensors, this device offers eight analog input channels and adheres to essential compliance certifications It can withstand storage temperatures between -40 °C and +85 °C, while operating efficiently in temperatures ranging from -20 °C to +60 °C.

With compact dimensions of 76 mm deep, 120 mm tall, and 115 mm wide, this unit weighs just 91 g For hassle-free installation, it employs a PUSH IN connection type, accommodating various wire sizes for reliable and secure setup.

Features and Benefits:

•Individual channel diagnostics available.

•Supports multiple types of temperature sensors, including Pt100, Ni100, etc..

•Reverse polarity protection included.

•High measurement accuracy with a range of -200 °C to 850 °C for temperature sensing.

Specifications:
