Description:
Introducing a versatile remote I/O module specifically crafted for IP20 applications, featuring an integrated safety SIL power supply This module complies with multiple standards, including ROHS, and holds notable certifications such as E141197 for UL, ensuring reliability in various operational contexts
Equipped with digital inputs and outputs, this module provides comprehensive diagnostics for both individual channels and the overall system.
Noteworthy safety features include short-circuit detection and wire break detection, adding an extra layer of protection Operating within a broad temperature range, this module is adaptable and compatible with multiple wire connections, making it an excellent choice for diverse applications while meeting stringent safety and environmental standards.
Features and Benefits:
•Certifications for safety including ROHS and cULus.
•Individual channel diagnosis for digital inputs and outputs.
•Short-circuit and wire break detection.
•Push-in type connection for ease of use.
•Wide operational temperature range.
Specifications:
| Depth | 76 mm |
| Height | 120 mm |
| Width | 11.5 mm |
| Net weight | 82 g |
| Operating temperature | -20 °C...60 °C |
| Storage temperature | -40 °C ... +85 °C |
| Air humidity (operation) | 10% to 95%, non-condensing as per DIN EN 61131-2 |
| Power supply | {'Supply voltage': '24 V DC +20 %/ -15 %', 'Current consumption from I IN': '35 mA', 'Feed current for I OUT (output current path), max': '8,050 mA'} |
| Field bus protocol | ['PROFINET IRT', 'PROFINET RT', 'CC-Link IE TSN', 'IEC 61162-450', 'PROFIBUS DP-V1', 'EtherCAT', 'Modbus/TCP', 'EtherNet/IP', 'CANopen', 'DeviceNet', 'POWERLINK', 'CC-Link'] |
| Safety characteristics | {'HFT (hardware fault tolerance), inputs': '1', 'Proportion of safety-related outages (SFF)': '98 %'} |
| Dimensions | {'Depth (inches)': '2.992', 'Height (inches)': '4.724', 'Width (inches)': '0.453'} |
| Galvanic isolation | 500 V DC between the current paths |
| Transmission speed of system bus, max | 48 Mbit |
