1506910000 - 4-Channel Analog Remote I/O Module, IP20, 16-Bit

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the Remote I/O module, specifically engineered to manage 4-channel analog signals for both current and voltage inputs, featuring an impressive 16-bit resolution With an IP20 rating, this reliable module meets RoHS compliance standards and is backed by specific UL certifications for quality assurance Measuring 76 mm deep, 120 mm tall, and 115 mm wide, it has a light weight of just 72 grams.

This module operates effectively across a broad temperature range of -20 °C to +60 °C and is capable of withstanding storage temperatures between -40 °C and +85 °C Additionally, it offers individual channel diagnostics and reverse polarity protection for enhanced functionality and safety.

Features and Benefits:

•Individual channel diagnosis for fault detection.

•Reverse polarity protection for safety.

•Short-circuit proof design enhancing reliability.

•High precision with an accuracy of 0.1% FSR.

•Fast conversion time of 1 ms.

Specifications:
