4329610000 - IP65 Rated EPDM Seal for Secure Enclosures (Pack of 10)
4329610000 - IP65 Rated EPDM Seal for Secure Enclosures (Pack of 10)
SKU: SKU: 4329610000 Download PDF
- 4329610000 - IP65 Rated EPDM Seal for Secure Enclosures (Pack of 10)
- 4329610000 - IP65 Rated EPDM Seal for Secure Enclosures (Pack of 10)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the RKDG D9 PT6, featuring a foldable seal and a specialized Field Power sealing insert This component boasts a robust IP65 protection rating, making it ideal for use in various EPDM material housings or enclosures Adhering to RoHS standards, this product also promotes environmental responsibility It is conveniently available for purchase in packs of ten.
Features and Benefits:
•Foldable seal design.
•IP65 protection rating with corresponding housing.
•Compliant with RoHS regulations.
•Constructed from EPDM material.
•Used for sealing applications in field power environments.
Specifications:
| Depth | 18 mm |
| Height | 33.8 mm |
| Width | 46.7 mm |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...85 °C |
| Basic material | EPDM |
| Colour | black |
| Protection degree | IP65 with corresponding housing |
| Line type | round |
| Outer cable diameter, min. | 7 mm |
| Outer cable diameter, max. | 9 mm |
| Net weight | 26.2 g |
