8000114905 - 340mm Stainless Steel Terminal Box for Versatile Applications

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the KTB GP XX3520 AB S4 PE terminal box, expertly crafted for a range of applications Measuring 340 mm in height, 167 mm in width, and featuring a depth of just 3 mm, this robust enclosure is made from high-grade stainless steel 14404 (316L) with a stunning electropolished silver finish Equipped with gland plates on both the top and bottom, it is designed for secure screw mounting This terminal box meets RoHS standards and doesn't contain any SVHC above 0.

1 wt%, making it both safe and reliable Its versatile design makes it suitable for use in the process industry and in environments with explosion risks.

Features and Benefits:

•Constructed from stainless steel 1.4404 (316L).

•Electropolished surface finish.

•Includes gland plates at the top and bottom.

•Suitable for screw mounting.

•Protection class (UL) rated as Type 3, Type 4X, and Type 12.

•Used in the process industry.

•Suitable for installation in explosive risk zones.

Specifications:
