1194820003 - 350mm Stainless Steel Terminal Box for Explosive Zones

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the Klippon TB MH (Terminal Box - Multi Hinge), a sophisticated unfilled enclosure crafted from durable stainless steel Measuring 350 mm in height, 260 mm in width, and 150 mm in depth, this robust enclosure meets environmental standards, including RoHS compliance It proudly holds multiple certifications, such as cULus and ATEX, making it suitable for a range of applications With versatile cable gland configurations, this enclosure is ideal for environments susceptible to explosive hazards, particularly in the chemical, oil and gas, and offshore sectors.

Features and Benefits:

•Constructed from stainless steel 1.4301 (304), untreated.

•Impact resistance of 7 J for ATEX version.

•Lid attached using 4 hinges and M6 hex-head slotted screws.

•Max payload capacity of 36 kg.

•Provided with IP66 and IP67 protection degrees.

•Explosive risk zone.

•Process industry.

•Oil and gas industry.

•Chemical industry.

•Offshore.

•Onshore.

Specifications:
