2902930000 - IP66 M20 Connector, -40°C to 60°C, 30V Capacity

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAI-08D-VPPP-5A-M12O-OL2-EX, a robust connector engineered for compatibility with operational voltages up to 30 V This model does not include an LED or LED initiator, making it an ideal choice for straightforward applications It adheres to RoHS certification and contains no substances of very high concern (SVHC) above 01 wt% Featuring a convenient PUSH IN connection method, this connector is enhanced with an M20 cable gland, allowing for a clamping range of 0.

14 mm² to 15 mm² It supports various wire sizes, accommodating standards from AWG 26 to AWG 16, and is suitable for both solid and flexible wire types The housing is constructed from black Pocan, comparable to RAL 9005, and offers a high degree of protection with an IP66/IP67 rating, making it resistant to dust and water Additionally, the unit operates effectively within a temperature range of -40°C to 60°C and can handle a current of up to 0.

8 A per slot, with a total maximum current rating of 08 A This connector is built for durability and reliability in diverse environments.

Features and Benefits:

•RoHS compliant without exemption.

•Includes 2 protection caps M12 and 1 cable gland M20x1.5.

•Plugging cycles rated to ≤ 50.

•Material housing color is black (similar to RAL 9005).

Specifications:
