2819130000 - 10m M8 Passive Distributor, 3 Poles, IP67 Rated

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the convenience of our passive distributor, designed specifically for sensor-actuator applications With a generous length of 10 meters, this device comes equipped with 3 poles and 4 contact sockets, ensuring versatile connectivity It adheres to RoHS standards and boasts an environmental compliance certification with no SVHC present above 01 wt% This distributor operates efficiently with a voltage range of 15 V to 30 V and can handle up to 2 A per contact socket.

Built to withstand harsh conditions, it functions flawlessly in temperatures varying from -25°C to 80°C, all while being protected by an IP67 rated casing for superior durability.

Features and Benefits:

•RoHS Compliant without exemption.

•IP67 protection degree.

•Maximum current of 2 A per slot.

•Bending cycles rated for 2 million.

•Sheath material is PUR, black in color.

•Cable length of 10 m.

•Shielded design.

Specifications:
