1859120000 - 12-Pole M23 Connector with LED Indicator and IP67 Protection

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAI-8-SH 4P FC, a reliable 12-pole connector featuring an M23 outlet, crafted for performance in extreme conditions with an operational temperature range of -25 to 80°C This unit adheres to RoHS standards and is engineered to handle a maximum voltage of 30 V, accommodating a current of up to 9 A With an integrated LED indicator, durability is ensured through the use of robust materials, including PA 6 GF and a nickel-plated CuZn screw socket.

Offering an impressive IP67 protection rating and presented in a sleek grey housing, this connector is built to withstand the rigors of various applications.

Features and Benefits:

•LED indicator for operation.

•A-coded plug-in station coding.

•Compatible with M12 connection thread.

•Protection against environmental factors rated IP67.

•RoHS compliant with exemption.

•Housing color is grey, RAL 7032.

Specifications:
