Description:
Introducing a high-performance PCB plug-in connector, expertly crafted as a female connection with a pitch measurement of 750 mm and accommodating 6 poles This connector adheres to IEC standards, capable of handling a rated voltage of 1000 V and supporting a current capacity of up to 346 A with wire cross-sections ranging from 05 to 4 mm² The component is UL rated for currents up to 185 A for wire gauges between AWG 20 to AWG 12.
With dimensions of 3495 mm in depth and 155 mm in height, it weighs just 33887 g Moreover, it is engineered to withstand a temperature spectrum of -40 °C to 85 °C, making it a reliable choice for diverse applications.
Features and Benefits:
•Compliant with RoHS without exemptions.
•Safe from finger touch as per DIN VDE 57 106.
•Minimum 25 plugging cycles.
•Stripping lengths between 8 mm and 10 mm.
•Touch-safe protection with an IP 20 rating.
Specifications:
| Rated Voltage (IEC) | 1000 V |
| Rated Current (IEC) | 34.6 A |
| Depth | 34.95 mm |
| Height | 15.5 mm |
| Ambient Temperature | -50 °C…125 °C |
| Insulating Material | PBT GF |
| Rated Voltage (UL 1059) | 1000 V |
| Rated Current (UL 1059) | 18.5 A |
| Number of Poles | 6 |
| Pitch | 7.5 mm |
| Connection Method | SNAP IN |
| Operating Temperature (min) | -40 °C |
| Operating Temperature (max) | 85 °C |
