8000085263 - 8-Pole Male Header PCB Connector, 7.50mm Pitch, RoHS Approved (Pack of 9)
8000085263 - 8-Pole Male Header PCB Connector, 7.50mm Pitch, RoHS Approved (Pack of 9)
SKU: SKU: 8000085263 Download PDF
- 8000085263 - 8-Pole Male Header PCB Connector, 7.50mm Pitch, RoHS Approved (Pack of 9)
- 8000085263 - 8-Pole Male Header PCB Connector, 7.50mm Pitch, RoHS Approved (Pack of 9)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing a versatile male header PCB plug-in connector, perfect for THT/THR soldering applications With a spacing of 750 mm and a configuration of 8 poles, this connector offers reliable performance Packaged conveniently in a tube, it complies with RoHS standards, ensuring it meets environmental guidelines It supports a range of voltage and current ratings according to both IEC and UL specifications, making it a dependable choice for your electronic projects.
Features and Benefits:
•Designed for THT/THR solder connection.
•Tube packaging.
•Compliance with RoHS standards.
•Low mounting height options.
•Able to withstand extreme ambient temperatures.
Specifications:
| Depth | 14.8 mm |
| Height | 15.1 mm |
| Rated voltage | 630 V |
| Rated current (IEC) | 30.4 A |
| Solder pin length | 3.2 mm |
| Insulating material | PA 9T |
| Contact base material | CuMg |
| Operating temperature range | -40 °C to 85 °C |
| Storage temperature range | -25 °C to 55 °C |
| Number of poles | 8 |
| Pitch in mm | 7.5 mm |
| Ambient temperature range | -50 °C to 125 °C |
