8000078343 - 8-Pole PCB Connector, 7.5mm Pitch, THT/THR, 90° Angle (Pack of 10)
8000078343 - 8-Pole PCB Connector, 7.5mm Pitch, THT/THR, 90° Angle (Pack of 10)
SKU: SKU: 8000078343 Download PDF
- 8000078343 - 8-Pole PCB Connector, 7.5mm Pitch, THT/THR, 90° Angle (Pack of 10)
- 8000078343 - 8-Pole PCB Connector, 7.5mm Pitch, THT/THR, 90° Angle (Pack of 10)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the MHS 7S/04-5/04 H T3 B T PCB plug-in connector, engineered specifically for male header interfaces This robust component supports THT/THR soldering and offers an 8-pole configuration with a connector pitch of 750 mm, featuring a convenient 90° elbow It meets global safety requirements and holds both ROHS and UL certifications, ensuring reliability and compliance for your electronic projects.
Features and Benefits:
•THT/THR solder connection type.
•Compliant with ROHS standards without exemptions.
•Constructed with insulating material PA 9T.
•Meets environmental compliance for REACH SVHC.
•Pin series quantity of 1.
•Plugging cycles rated at ≥ 25.
Specifications:
| Rated Voltage (IEC) | 630 V |
| Rated Current (IEC) | 30.4 A |
| Depth | 14 mm |
| Height | 15.1 mm |
| Ambient Temperature | -50 °C…125 °C |
| Operating Temperature (Min) | -50 °C |
| Operating Temperature (Max) | 100 °C |
| Storage Temperature (Min) | -25 °C |
| Storage Temperature (Max) | 55 °C |
| Number of Rows | 1 |
| Contact base material | CuMg |
| Insulating Material Group | I |
| Moisture Level | 1 |
| Rated Imulse Voltage (Pollution Degree II/2) | 4 kV |
| UL Voltage Rating | 300 V |
