2674530000 - Dark Beige 2.5 mm² Feed-Through Terminal Block, 24A, 800V (Pack of 100)
2674530000 - Dark Beige 2.5 mm² Feed-Through Terminal Block, 24A, 800V (Pack of 100)
SKU: SKU: 2674530000 Download PDF
- 2674530000 - Dark Beige 2.5 mm² Feed-Through Terminal Block, 24A, 800V (Pack of 100)
- 2674530000 - Dark Beige 2.5 mm² Feed-Through Terminal Block, 24A, 800V (Pack of 100)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the S2C 25 feed-through terminal block, expertly designed with a snap-in mechanism This dark beige component accommodates wires with a cross-section of 25 mm² and supports a maximum current of 24 A, along with a voltage rating of 800 V Equipped with two connection points, this terminal block is also RoHS compliant Its compact dimensions measure 51 mm in width, 38 mm in depth, and 59 mm in height, weighing just 8.
447 grams Perfect for a range of electrical applications, this terminal block combines functionality with reliability.
Features and Benefits:
•Snap-in mounting type.
•Compliant with RoHS standards.
•Designed for maximum ambient temperature of 130 °C.
•UL 94 flammability rating of V-0.
Specifications:
| Depth | 38 mm |
| Height | 59 mm |
| Width | 5.1 mm |
| Storage temperature | -25 °C...55 °C |
| Ambient temperature | -5 °C |
| Continuous operating temp., min. | -60 °C |
| Continuous operating temp., max. | 130 °C |
| Rated cross-section | 2.5 mm² |
| Rated voltage | 800 V |
| Nominal current | 24 A |
| Number of connections | 2 |
| Mounting rail | TS 35 |
| Material | Wemid |
| Connection type | SNAP IN |
| Wire connection cross section AWG, max. | AWG 14 |
| Wire connection cross section AWG, min. | AWG 22 |
