2647270000 - OMNIMATE 5.08mm Signal Connector, 4 Poles, 180° Clamping (Pack of 180)

Description:

Introducing the OMNIMATE Signal series connection device, tailored for field applications This unit utilizes clamping yokes and has a compact pitch of 508 mm It boasts a 180-degree conductor outlet direction and supports four poles With a rated voltage of 630 V and a maximum current of 22 A as per IEC standards, it also complies with UL standards, handling up to 300 V and 15 A The clamping range starts at 0.

2 mm² and can extend to 25 mm² Constructed with copper alloy contacts that have a tinned finish, this device is encased in a pale green insulating material It is capable of withstanding storage temperatures as low as -40 °C and up to 70 °C, while operating at a maximum temperature of 105 °C.

Features and Benefits:

•Compliant with RoHS and REACH regulations.

•Utilizes a clamping yoke connection method for secure wiring.

•Excellent insulation resistance of 500 MΩ.

•Low flammability rating (UL 94 V-0).

•Designed for long-term use in challenging environments with a temperature range from -40 °C to 105 °C.

•Field connections in electrical systems.

•OMNIMATE basic product compatibility.
