2648480000 - 5.08mm Pitch OMNIMATE Signal Connector with 90° Elbow (Pack of 120)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE signal connector, expertly crafted for seamless board connections This connector features a practical 508 mm pitch and a convenient 90° outgoing elbow It accommodates 10 poles, each equipped with a solder pin measuring 39 mm in length With an overall length of 4572 mm, it's designed for efficient use in various applications Constructed from PA GF, this connector showcases a visually appealing pale green color that meets the RAL 6021 standard.

It is rated to handle a current of 15 A and is capable of withstanding voltages of 630 V as per standard IEC specifications and 300 V with CSA recognition Both the contact base and the pins are made from a durable copper alloy finished with a matt tinning for added reliability Safety is paramount, and this connector carries a UL 94 flammability rating of V-0, ensuring a secure performance Please remember, in accordance with the IEC 61984 standard, to avoid engaging or disengaging the connectors under live or loaded conditions.

Features and Benefits:

•Compliant with RoHS and REACH regulations.

•Rated current of 15 A with a storage temperature range of -40 °C to 70 °C.

•Max operating temperature up to 105 °C.

•THT solder connection suitable for board mounting.

•Only compatible with OMNIMATE basic products.

Specifications:
