2648890000 - 5.08mm 10-Pole Connector with 90° Elbow, RoHS Compliant (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CHDV 508/10/90G 35SN GN BX connector, a reliable choice compliant with RoHS directives and UL certified—verification can easily be conducted through the UL website Weighing in at 775 grams, this component is part of the OMNIMATE Signal series, making it perfect for board connections with its THT soldering capability The connector features a 508 mm pitch and is designed with a 90-degree outgoing elbow for enhanced connectivity.

It comprises 10 poles, equipped with solder pins measuring 35 mm in length, tailored for efficient soldering Constructed from high-quality materials, including PA GF for insulation, this connector comes in a subtle pale green hue that corresponds with RAL 6021.

Features and Benefits:

•Compatible only with OMNIMATE basic products.

•UL 94 flammability rating V-0.

•Insulating material group I.

•Storage temperature range from -40 °C to 70 °C.

•Rated impulse voltage for various pollution degrees at 4 kV.

•Compliant with IEC standards.

Specifications:
