2647780000 - 5.08mm 90° Connector, UL Certified, 9-Pole Pale Green (Pack of 36)

Description:

Experience dependable connectivity with the CPS 508/09/90F SN GN BX connector This component is ROHS compliant and bears UL certification (Certificate No E60693), making it perfect for field connections With a pitch of 508 mm, this connector features nine poles and a 90° conductor outlet orientation Made from durable PA insulating material, it comes in a soft pale green shade (RAL 6021) Compatible with wire sizes ranging from 0.

2 to 4 mm², this connector is engineered to handle up to 22 A and 630 V according to IEC standards, along with UL and CSA ratings for up to 300 V The robust construction incorporates a copper alloy for the contact points, coated with tin for added longevity and reliability across a variety of applications.

Features and Benefits:

•Pale green color RAL 6021.

•Solid, stranded, and flexible conductor options.

•Clamping yoke connection.

•90° conductor outlet direction.

•Plugging cycles rated for up to 25.

•Suitable for long-term storage under specified conditions.

•Field connection applications in various electronic devices.

Specifications:
