2648320000 - 17-Pole 5.08mm Electrical Connector, RoHS Compliant, 81.28mm Long (Pack of 21)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 508/17/270F SN GN BX, a versatile electrical connection component engineered for efficient field connections utilizing a reliable clamping yoke method This component meets RoHS compliance and features a compact connector pitch of 508 mm, accommodating up to 17 poles With dimensions of 8128 mm in length and a stripping length of 7 mm, it is designed for wire connections ranging from 0.

2 mm² to 4 mm² The CPS 508/17/270F is compatible with various international standards, including IEC and UL Crafted from durable copper alloy for the contacts and PA for insulation, it operates efficiently in a temperature range of -40 °C to 105 °C, making it an ideal choice for diverse applications.

Features and Benefits:

•RoHS compliant.

•Compatible with OMNIMATE basic products.

•Single-row design.

•Low stripping length.

•Clamping force retention.

•Provides high insulation resistance.

Specifications:
