2648210000 - 5.08mm Pitch Connector, 6 Poles, 270° Outlet Direction (Pack of 54)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the CPS 508/06/270F SN GN BX connector, a reliable option that complies with RoHS standards and is UL certified Engineered for easy field connections, this connector employs a clamping yoke method for securing wires With a compact pitch of 508 mm, it can handle up to 6 poles and offers a unique outlet direction of 270° It efficiently connects conductors ranging from 02 mm² to 4 mm², compatible with AWG sizes from 26 to 14.

Built to withstand extreme conditions, this device operates safely in temperatures between -40 °C and 105 °C, making it a dependable choice for various applications Its components are crafted from high-quality insulating and contact materials, ensuring optimal performance and safety.

Features and Benefits:

•RoHS compliant with an exemption.

•Tightening torque between 0.5 Nm and 0.55 Nm for secure connections.

•Plugging cycles allow for 25 uses.

•Designed for a broad range of conductor connections.

•Field connection in electrical systems.

Specifications:
