2647980000 - 6-Pole Connector, 630V, 22A, RoHS Compliant, 180° Outlet (Pack of 90)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 508/06/180F SN GN BX connector, a compliant choice meeting RoHS standards This connector is engineered for high performance, operating at 630 V and handling a maximum of 22 A It accommodates wire sizes from 02 to 25 mm² and boasts a UL rating of 300 V at 15 A, compatible with AWG sizes ranging from 30 to 12 Ideal for field connectivity, it utilizes a clamping yoke connection and features a convenient 180-degree conductor outlet direction.

Each unit includes 6 poles arranged in a single row and comes packaged ready for use.

Features and Benefits:

•Designed for field connection.

•Utilizes clamping yoke connection method.

•Supports a conductor outlet direction of 180°.

•Maximum plugging cycles rated at 25.

•Robust tightening torque specifications.

Specifications:
