2646490000 - 21-Pole Connector, PA GF, 3.9mm Pins, 630V Rated (Pack of 65)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/21/180G 39SN GN BX connector, a reliable solution for board connections via THT soldering This component boasts an IEC certification of 630 V at 15 A and a UL certification of 300 V at 15 A, showcasing its high performance and safety standards Housed in sturdy packaging, this connector weighs 819 g and adheres strictly to RoHS compliance, with no SVHC present above 01 wt% Featuring a compact single row design with 21 poles, each equipped with a solder pin measuring 3.

9 mm, this connector can operate efficiently in temperatures ranging from -40 °C to 105 °C Constructed with PA GF insulating material, its eye-catching pale green color offers both functionality and style Additionally, the copper alloy used for the contact base and surface is finished with a tinned matte coating, enhancing durability and performance.

Features and Benefits:

•Compliant with RoHS.

•Operating temperature range from -40 °C to 105 °C.

•UL 94 flammability rating of V-0.

•Designed for use with OMNIMATE basic products.

Specifications:
