2646350000 - 15A 14 Pole CH Connector, 65mm, RoHS Compliant (Pack of 100)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/14/180G 39SN GN BX connector, specially engineered for seamless board connections With a rated current of 15 A, this versatile connector operates across a voltage range of 630 V and 300 V Crafted from a pale green insulating material, it adheres to RoHS compliance for environmentally friendly performance Designed for ease of use, the connection method utilizes THT soldering on the PCB, featuring a convenient pitch of 5 mm.

It measures 65 mm in length and includes 14 individual poles, each equipped with a solder pin This product comes with the assurance of relevant certifications, including a cURus certificate, guaranteeing its quality and reliability for your projects.

Features and Benefits:

•Pale green color similar to RAL 6021.

•Insulating material is PA GF.

•Flammability classified as UL 94 V-0.

•Storage temperature range from -40 °C to 70 °C.

•Operating temperature can reach up to 105 °C.

•Compatible only with OMNIMATE basic products.

Specifications:
