2646030000 - 21-Pole Elbow Connector, 5mm Pitch, RoHS Compliant (Pack of 65)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/21/90G 39SN GN BX, a top-tier component that meets RoHS standards and boasts certifications like E60693 from UL Capable of supporting a current of 15 A, it operates efficiently at an IEC voltage rating of 630 V and a UL voltage rating of 300 V Weighing in at just 819 g and packaged in a sturdy box, this product is part of the OMNIMATE Signal family Engineered for Through-Hole Technology (THT) solder connections, it features a pin pitch of 5 mm and includes a 90° elbow connection.

The configuration comprises 21 poles, each equipped with a solder pin Additional specifications include precise dimensions for both solder pin and eyelet The body is composed of pale green PA GF, adhering to the RAL 6021 standard and achieving a UL 94 flammability rating of V-0 The contact materials consist of a durable Cu-alloy with a tinned finish, ensuring reliability and performance in various applications.

Features and Benefits:

•Compliant with RoHS without any exemptions.

•Maximum storage temperature of 70 °C.

•Operating temperature can go up to 105 °C.

•Long-term storage capability for up to 36 months under specified conditions.

•Designed for compatibility with OMNIMATE basic products.

Specifications:
