2645920000 - 16-Pole 90° Connector, 3.9mm Pins, RoHS Compliant (Pack of 75)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/16/90 39SN GN BX connector, engineered for secure board connections via THT soldering This connector adheres to IW standards, featuring robust ratings of 630 V and 15 A according to IEC guidelines, and 300 V with the same current rating under UL standards Its unique 90° elbow design includes 16 poles, each fitted with a 39 mm solder pin Crafted from PA GF insulating material, this connector is fully RoHS compliant without any exemptions and satisfies multiple quality standards for both IEC and UL contexts.

Features and Benefits:

•RoHS compliant without exemption.

•Designed for THT solder connections.

•Low flammability rating of V-0.

•Compatible only with OMNIMATE basic products.

•Connectors should not be engaged or disengaged while live.

Specifications:
