2645400000 - 24-Pole THT Connector, 15A, 630V, Pale Green (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/24/90F 39SN GN BX connector, engineered for dependable board connections through THT soldering This robust connector supports a maximum current of 15 A and is capable of handling voltages up to 630 V With a 5 mm pitch and 24 poles, each equipped with a solder pin measuring 39 mm in length, it ensures optimal performance Its exterior features a soft pale green hue, compliant with RAL 6021 standards.

This versatile connector carries cURus certification number E60693 and adheres to RoHS guidelines, ensuring it meets environmental safety standards.

Features and Benefits:

•Compliant with RoHS and supports exemption.

•Suitable for both board connections and mounting onto PCBs.

•Insulating material complies with UL 94 V-0 flammability rating.

•Designed for long-term storage with stringent temperature and humidity requirements.

•Only compatible with OMNIMATE basic products.

Specifications:
