2645120000 - Compact 19-Pole Connector, 5mm Pitch, 18A, Up to 630V (Pack of 21)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 500/19/270F SN GN BX, an ideal solution for seamless field connectivity across various wire types This connector meets IEC standards, confidently handling voltages up to 630 V and a current rating of 18 A Featuring a practical clamping yoke connection method, it has a compact design with a 5 mm pitch and a single row housing that accommodates 19 poles, making it adaptable to multiple applications.

It is compatible with wire cross-sections ranging from 02 mm² to 4 mm² Built with robust insulating materials, this product ensures reliable performance in a wide array of conditions and is engineered to operate in temperatures from -40°C to 105°C.

Features and Benefits:

•Clamping range supports wire sizes between 0.2 mm² to 4 mm².

•Compact and efficient design with 19 poles in a single row.

•Suitable for use in environments with temperatures from -40°C to 105°C.

•Clamping yoke connection method ensures secure wire connections.

•Compliant with both RoHS and UL standards for safety and environmental sustainability.

Specifications:
