2644760000 - 6-Pole OMNIMATE Signal Clamp, 5mm Pitch, 11.3g, ROHS Compliant (Pack of 90)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The CPS 500/06/180F SN GN BX is an environmentally compliant product that adheres to ROHS standards and comes in convenient box packaging It has a lightweight design, weighing only 113 grams, making it easy to handle This component operates effectively with voltage ratings of IEC: 630 V / 22 A / 02 - 25 mm² and UL: 300 V / 15 A / AWG 30 - AWG 12 Part of the OMNIMATE Signal series (BL/SL 508), it features a clamping yoke connection and a compact 5 mm pitch.

Equipped with six poles, it offers a tightening torque between 05 and 055 Nm, ensuring secure connections With a plugging cycle rating of 25, it can withstand a maximum plugging force of 9 N and pulling force of 6 N per pole, making it a reliable choice for various applications.

Features and Benefits:

•Environmentally compliant with ROHS and REACH.

•Clamping range from 0.2 mm² to 4 mm² for different wire types.

•Easy-to-use clamping yoke connection for field connection.

•Suitable for various electrical and electronic applications requiring stable connections.
