2644720000 - 5mm Pitch UL Certified Signal Connector, 22A Capacity (Pack of 180)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience reliable performance with the CPS 500/02/180F SN GN BX, a product that meets RoHS compliance and is UL certified (certificate number E60693) It operates under an IEC standard of 400 V, accommodating a maximum current of 22 A, and supports wire sizes from 02 to 25 mm² For UL criteria, this device runs efficiently at 300 V with a current capacity of 15 A, suitable for AWG wire sizes ranging from 30 to 12.

Packaged in a convenient box, this item weighs just 43 g As a member of the OMNIMATE Signal family, it features field connection capabilities and utilizes a robust clamping yoke connection method Key specifications include a 5 mm pitch and a robust maximum plugging cycle of 25, ensuring optimal electrical efficiency and performance.

Features and Benefits:

•Clamping yoke connection method.

•Filed connection type.

•Pitch of 5 mm.

•Operating temperature maximum of 105 °C.

•Storage temperature range of -40 °C to 70 °C.

•Insulation resistance of 500 MΩ.

•UL 94 flammability rating of V-0.

•Copper alloy contact material.
