2643710000 - 3.81mm Pitch Board Connector with 180° Elbow, 12 Poles (Pack of 234)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 381/12/180G 35SN GN BX, a high-end component for board connections tailored for demanding electronic tasks This element is designed to seamlessly integrate with the OMNIMATE Signal series, specifically models BL/SL 508, and features a pitch of 381 mm It operates effectively within a voltage threshold of 320 V and supports a current up to 8 A Each package includes 234 units, making it a reliable choice for bulk needs.

Notably, it includes a 180° outgoing elbow, offers 12 poles with a dedicated solder pin for each, and features a solder pin length of 35 mm, ensuring optimal performance for your electronic setups.

Features and Benefits:

•ROHS compliant without exemption.

•Insulating material is PA GF.

•features a UL 94 flammability rating of V-0.

•Storage temperature ranges from -40 °C to 70 °C.

•operating temperature up to 105 °C.

•Manufactured from a Cu-alloy contact base material.

Specifications:
