2643610000 - 3.81mm 2-Pole RoHS Compliant Connector, 8A, 320V (Pack of 700)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 381/02/180G 35SN GN BX, a reliable component from the OMNIMATE Signal series This connector is rated for a current of 8 A and supports a voltage up to 320 V in line with IEC standards It features a THT solder joint for secure and efficient board attachments With a pin pitch of 381 mm, it incorporates 2 poles, each equipped with a 35 mm long solder pin Specifically designed for PCB mounting, this device meets RoHS standards and is completely non-hazardous, aligning with REACH regulations.

Crafted from pale green PA GF insulating material, reminiscent of RAL 6021, it ensures both durability and reliability The solder connections are made from a robust copper alloy, making it suitable for various environmental conditions.

Features and Benefits:

•Compatible with OMNIMATE basic products.

•Rated current related to rated cross-section and minimum number of poles.

•Non-breaking capacity connectors according to IEC 61984.

•Designed for long-term storage in controlled temperature and humidity conditions.

Specifications:
