2643050000 - RoHS Compliant CH 3.81/03/90F with UL Certification (Pack of 576)

2643050000 - RoHS Compliant CH 3.81/03/90F with UL Certification (Pack of 576)

SKU: 2643050000 Download PDF

Variant:
  • 2643050000 - RoHS Compliant CH 3.81/03/90F with UL Certification (Pack of 576)
Now $830.82
BEFORE   $0.00 Now $830.82
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 381/03/90F 35SN GN BX, a product that meets RoHS compliance under exemption 6c, making it an environmentally friendly choice for a variety of applications This item boasts a UL certification with reference number E60693, ensuring its safety and quality for your needs.

Features and Benefits:

    •Contains a net weight of 1.64 g.

    •Outward elbow is at a 90° angle.

    •Package comprises a box.

    •Compatible only with OMNIMATE basic products.

    •Designed for long-term storage at an average temperature of 50 °C and maximum humidity of 70% for 36 months.

Specifications:

 IEC 320 V / 8 A
 UL 300 V / 8 A
 Pitch in mm (P) 3.81 mm
 Number of poles 3
 Solder pin length (l) 3.5 mm
 Solder pin dimensions 0.8 x 0.8 mm
 Solder eyelet hole diameter (D) 1.3 mm
 Material data {'Insulating material': 'PA GF', 'Contact base material': 'Cu-alloy', 'Contact material': 'Cu-alloy', 'Contact surface': 'tinned', 'Tinning type': 'matt'}
 Storage temperature, min. -40 °C
 Storage temperature, max. 70 °C
 Operating temperature, max. 105 °C
 Rated data acc. to IEC {'Rated current, min. number of poles (Tu=20°C)': '8 A', 'Rated voltage for surge voltage class / pollution degree II/2': '320 V', 'Rated voltage for surge voltage class / pollution degree III/2': '160 V', 'Rated impulse voltage for surge voltage class/ pollution degree II/2': '2.5 kV'}
 Rated data acc. to CSA {'Rated voltage (Use group B / CSA)': '300 V', 'Rated current (Use group B / CSA)': '8 A'}
 Rated data acc. to UL 1059 {'Institute (cURus)': 'CURUS', 'Certificate No. (cURus)': 'E60693', 'Rated voltage (Use group B / UL 1059)': '300 V', 'Rated current (Use group B / UL 1059)': '8 A'}
 VPE dimensions {'length': '172 mm', 'width': '137 mm', 'height': '49 mm'}
