2642880000 - 5-Pole Connection Device for 0.2-1.5 mm² Wires (Pack of 144)

2642880000 - 5-Pole Connection Device for 0.2-1.5 mm² Wires (Pack of 144)

SKU: 2642880000 Download PDF

Variant:
  • 2642880000 - 5-Pole Connection Device for 0.2-1.5 mm² Wires (Pack of 144)
Now $639.94
BEFORE   $0.00 Now $639.94
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/05/270F SN GN BX, a reliable connection device designed to meet multiple industry standards, including RoHS compliance and UL certification This device excels in making field connections through clamping yoke methods It supports wire sizes ranging from 02 to 15 mm² (AWG 30 to AWG 16), making it versatile for various applications With a conductor outlet direction of 270° and the capacity for up to five poles, it offers flexibility in installation.

Made from durable PA insulating material, this connection device features a hue that closely resembles RAL 6021.

Features and Benefits:

    •Supports a current rating of 8 A and a voltage rating of 320 V.

    •Durable with a plug cycle life of 25 cycles.

    •Insulation rated to V-0 for enhanced safety.

    •Ensures compatibility with OMNIMATE basic products.

Specifications:

 IEC rated voltage: 320 V
 IEC rated current: 8 A
 UL rated voltage: 300 V
 UL rated current: 8 A
 Pitch (mm): 3.81 mm
 Number of poles: 5
 Stripping length: 6.5 mm
 Tightening torque (min): 0.22 Nm
 Tightening torque (max): 0.25 Nm
 Storage temperature (min): -40 °C
 Storage temperature (max): 70 °C
 Operating temperature (max): 105 °C
 Material - Insulating: PA
 Material - Contact base: Copper alloy
 Material - Contact surface: tinned
 Clamping range (min): 0.2 mm²
 Clamping range (max): 1.5 mm²
