2642850000 - 3.81mm Electrical Connector for 2-Pole Field Connections (Pack of 250)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/02/270F SN GN BX, an expertly engineered electrical connector designed for efficient field connections Featuring a clamping yoke connection with a compact pitch of just 381 mm (015 inches), this connector is optimized for two-pole applications, allowing for conductor outlets in a 270° configuration With a robust rated voltage of 320 V and a current capacity of 8 A, this product meets IEC standards, making it reliable for various electrical needs.

It accommodates wire cross-sections from 02 mm² to 15 mm², equivalent to AWG 30 to AWG 16 Plus, it adheres to RoHS regulations, ensuring compliance with environmental standards for your peace of mind.

Features and Benefits:

•Compliant with ROHS regulations.

•Supports a variety of wire sizes from 0.2 mm² to 1.5 mm².

•Designed for field connection applications.

•Durable construction with a flammability rating of V-0.

•Easy to use clamping yoke connection method.

•This connector is compatible exclusively with OMNIMATE basic products.

Specifications:
