2642600000 - 15-Pole 3.81mm Clamping Connector, 90° Angle, 0.2-1.5mm² (Pack of 62)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS series connector from OMNIMATE basic, engineered for easy field connections using a clamping yoke method This reliable device supports conductor sizes ranging from 02 mm² to 15 mm², or AWG 30 to AWG 16, making it versatile for various applications With a compact pitch of 381 mm, it houses 15 poles and allows for a 90-degree conductor outlet angle It is capable of handling voltage ratings up to 320 V and a current of 8 A, while withstanding temperatures as high as 105 °C.

This product is compliant with RoHS and UL standards, ensuring quality and safety in operational settings.

Features and Benefits:

•95% of the material is recyclable.

•Designed for easy wire connections with a minimal stripping length of 6.5 mm.

•Can withstand 25 plugging cycles with a maximum plugging force of 12 N.

•Ideal for use in various industrial electrical connections requiring robust and reliable performance.

Specifications:
