2642440000 - 18-Pole 3.81mm Connector with 270° Clamping Range (Pack of 59)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/18/270 SN GN BX, a highly efficient connector engineered in compliance with RoHS and UL standards, making it suitable for a broad range of applications This connector boasts a convenient field connection design with a clamping yoke for secure wire attachments It features a unique conductor outlet angle of 270°, a compact pitch of 381 mm, and supports up to 18 poles With a clamping range that accommodates wires from 0.

2 mm² to 15 mm², it is versatile for various wiring setups and guarantees reliable connections Recognized under UL file number E60693, this connector is a dependable choice for your electrical needs.

Features and Benefits:

•Field connection method with clamping yoke connection.

•Compact design with a pitch size of 3.81 mm.

•Conductor outlet direction at 270°.

•Rated current capacity of 8 A.

•Rated voltage of 300 V for CSA.

•Compatible only with OMNIMATE basic products.

•Minimum pulling force per pole of 12 N.

Specifications:
