2642370000 - 3.81mm Connector for 11 Poles, 270° Outlet Direction (Pack of 90)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/11/270 SN GN BX connector, expertly crafted for field connections utilizing a secure clamping yoke method This product features a compact pitch of 381 mm and a versatile 270° outlet direction, accommodating up to 11 poles Operating at 320 V with a maximum current of 8 A according to IEC standards, it also meets UL specifications for 300 V and 8 A Made from durable PA insulating material, this connector comes in a soft pale green shade that adheres to RAL 6021.

RoHS compliant, it boasts a broad temperature range, functioning efficiently in conditions from -40 °C to 105 °C Each unit is delivered in a box and is designed for specific wire cross-sections to ensure compatibility.

Features and Benefits:

•Compliant with RoHS and REACH regulations.

•Effective operating temperature range from -40 °C to 105 °C.

•Constructed with a clamping yoke connection for reliable performance.

•Designed for use with OMNIMATE basic products.

Specifications:
