2642250000 - 3.81mm 18-Pole Connector, 320V, 8A, Secure Clamping (Pack of 66)

Description:

Introducing the CPS 381/18/180 SN GN BX connector, engineered for specialized needs with robust performance It accommodates voltages up to 320 V and currents up to 8 A, making it versatile for various applications This connector supports conductor sizes from 02 mm² to 15 mm² (AWG 30 to AWG 16) and features an efficient 180° outlet direction within a single-row design comprising 18 poles For secure connections, it employs a reliable clamping yoke mechanism.

Measuring with a pitch of 381 mm, this compact unit weighs just 135 g Crafted from PA insulating material, it also meets RoHS compliance standards, ensuring environmental safety .

Features and Benefits:

•Clamping yoke connection method for reliability.

•180° conductor outlet direction for space-saving design.

•Lightweight at 13.5 g for easier handling and installation.

•Screwdriver blade size of 0.4 x 2.5 for compatibility.

•Rated for a maximum of 25 plugging cycles.

•Field connection applications.

•OMNIMATE basic products compatibility.

Specifications:
