2642170000 - 10-Pole 180° Connector, 3.81mm Pitch, Field Connection (Pack of 126)

Description:

Introducing the CPS 381/10/180 SN GN BX connector, a robust solution tailored for field connections This model utilizes a clamping yoke for secure attachment and boasts a 180° conductor outlet with a pitch of 381 mm Featuring 10 poles arranged in a single row, it is designed for easy installation, requiring a minimum stripping length of 65 mm Operating effectively with tightening torque between 022 Nm and 0.

25 Nm, this connector accommodates a broad spectrum of conductor sizes, from 02 mm² to 15 mm², compatible with AWG sizes 30 to 16 Engineered to withstand harsh conditions, it functions within a temperature range of -40°C to 70°C and supports operational temperatures up to 105°C Additionally, this product meets RoHS compliance standards and comes neatly packaged in a box, making it an excellent choice for various applications.

Features and Benefits:

•Compatible only with OMNIMATE basic products.

•Designed for easy and effective installation with a maximum plugging force of 10 N.

•Can undergo up to 25 plugging cycles.

•Ensures reliable electrical connections across various wire sizes.

Specifications:
